The blocks need to not clog, the radiators need to not leak, the fittings need to remain watertight, and the pump needs to remain powered.
With water cooling, you are reliant on every part in the system working as it should, in order to have a functional cooling system. The Risk of AIOs (and Water Cooling overall) The AIO simply compresses this loop into a much smaller package, and removes the large maintenance issue that you get with a custom loop.
The now-cold water moves from the radiator back into the reservoir, and the cycle repeats. The fans on the radiator move the hot air away from the loop itself, and out of the case. The hot water goes to the radiator via the tubing, is run through the radiator fin array to dissipate the heat out of the loop entirely. The water block uses an array of extremely thin fins to increase the surface area from which the heat can dissipate, and water is run through those micro-fins to move the hot water away from the heat source. This heat is conducted to the water block which is laid on the IHS (there’s a thin layer of thermally conductive material between the IHS and water block, as the water block/IHS contact isn’t perfect). The CPU generates heat, which is conducted to the IHS (integrated heat spreader), or the shiny piece of metal with the CPU model written on it. The pump moves the cold water (and water overall) into the water block for the heat (CPU), and out of the water block. Large reservoirs can hold more water, which means less goofing around with a funnel and distilled water. The reservoir helps during loop filling/draining, and thus while isn’t totally necessary, is extremely helpful. Articulating elbow fittings make tubes easier to route while reducing tension on the pumpĬelsius+ is available in three different sizes: 240 mm, 360 mm and the all-new 280 mm model, each with your choice of Dynamic X2 or Prisma ARGB fans.The reservoir funnels cold water into the pump (generally directly below the reservoir).Low-permeability rubber tubing with nylon braided sleeves for extra durability and an added touch of style.Pre-applied thermal paste guarantees optimal application with even coverage.Asus AURA, Gigabyte Fusion, MSI Mystic Light, Razer Chroma and ASRock Polychrome support.Sleeved tubing with concealed wiring connects power and ARGB for the entire system at the pump.ARGB-enabled PWM hub places all fan connections directly on the radiator for a clutter-free installation.
#FRACTAL DESIGN 360 AIO FULL#
#FRACTAL DESIGN 360 AIO SERIES#
Cool, quiet and powerful – The new Celsius+ series of AIO coolers has just been announced by Fractal Design, featuring an ARGB-accented pump face, a fully redesigned block and an upgraded on-radiator PWM fan hub with ARGB support.Ĭleverly concealed wiring within the braided sleeves of the Celsius’ low-permeability rubber tubing allows the entire system to connect at the pump with just a single power plug and an (optional and detachable) ARGB cable.Īs with previous Celsius coolers, selectable auto/PWM modes offer dynamically optimized performance with the choice of full user control for expert fine-tuning.
